FENDER | ELECTRIC 12 | TECHNICAL INFORMATION

Fender 12-String Technical Specifications

Parts lists, schematics and wiring information

Fender regularly produced service information for dealers, with lists of components, along with part numbers, to help customers purchase correct replacement parts. Some are just plain lists, whilst others are illustrated or contain additional information, as is the case in 1968, when illustrations and circuit schematics were included. Click on the thumbnails for larger versions.

Fender 12-string 1968 replacement parts list (illustrated)

The 1968 sevice manual for the Fender electric 12-String is a single sheet folded to six panels, five of which are printed. It is more detailed than most, having a photograph of a typical instrument, a parts list with labelled blueprints and finally a circuit diagram showing pickups and controls.

Fender 12-String 1968 parts list page 1
Fender 12-String 1968 parts list page 2
Fender 12-String 1968 parts list page 3
Fender 12-String 1968 parts list page 4
Fender 12-String 1968 parts list page 5

Fender 12-string 1969 replacement parts list

This parts list is dated June 1969 - shortly after this model was withdrawn. These sheets are simply a list of parts and their numbers, without prices.

Fender 12-String 1969 parts list page 1
Fender 12-String 1969 parts list page 2
