VOX | PARTS | TREMOLOS

Vox guitar tremolos and tailpieces

Part descriptions for Vox vibratos / tremolos, bridges etc

Vox tremolos

Vox 1960s De Luxe tremolo Vox 1960s De Luxe tremolo Vox 1960s De Luxe tremolo

Vox De Luxe tremolo (JMI)

The Vox De Luxe Tremolo, or Ace De Luxe as it was also known was fitted to several solid body Vox guitars produced by JMI in their Dartford factory, UK. It was especially designed for models with a radiused fingerboard, appearing in the early 1960s on models such as the Ace, Super Ace, Escort and earliest versions of the Consort. In 1967 it was also fitted to one final model, the Vox Marauder.

Vox 1960s De Luxe tremolo Vox 1960s De Luxe tremolo Vox 1960s De Luxe tremolo

Vox standard tremolo (JMI)

The Vox Standard Tremolo, part 09-903-0, was produced for mid-sixties entry level UK-built solid bodies with flat fretboards. The de luxe (above) was the correct tremolo for guitars with radiused boards. It was fitted to the Dominator, Apache, and later versions of the Shadow, and Duotone, from 1963 onwards, and remained the correct part for these models right until the end of UK Vox guitar production in 1967.


Vox tailpieces

Vox Shadow/Stroller/Clubman 'hump' tailpiece Vox Shadow/Stroller/Clubman 'hump' tailpiece Vox Shadow/Stroller/Clubman 'hump' tailpiece

Vox 'hump' tailpiece (JMI)

The Vox 'hump' tailpiece (our name), was derived from the Guyatone tailpiece fitted to a number of late 1950s imported guitars, including the SB series. JMI's version was used on the early Vox Stroller and Vox Shadow guitars (those based on the 50s Guyatones) and also the one and two pickup Vox Clubman. This part was replaced by the 'wedge' tailpiece below in 1966.

Vox Clubman/Stroller 'wedge' tailpiece Vox Clubman/Stroller 'wedge' tailpiece Vox Clubman/Stroller 'wedge' tailpiece

Vox 'wedge' tailpiece (JMI)

The Vox Wedge tailpiece (again, our name), was a replacement part for the simpler 'hump' tailpiece above. It was fitted to the Stroller and Clubman models circa 1966-67.
