Gibson Pot Database: home
| Part number: 70041 Further details of the pots listed can be found by clicking on the Gibson part numbers | ||
| instrument model | part list | other pots for this guitar from this catalogue |
| Byrdland other pots listed for this model | 1981 Gibson parts list | 70029 70035 |
| ES-175 other pots listed for this model | 1981 Gibson parts list | 70029 70035 |
| ES-175D other pots listed for this model | 1981 Gibson parts list | 70029 70035 |
| ES-345TD other pots listed for this model | 1981 Gibson parts list | 70029 70035 |
| ES-350TD other pots listed for this model | 1981 Gibson parts list | 70029 70035 |
| ES-355TD other pots listed for this model | 1981 Gibson parts list | 70029 70035 |
| ES-355TD-SV other pots listed for this model | 1981 Gibson parts list | 70029 70035 |
| L-5 CES other pots listed for this model | 1981 Gibson parts list | 70029 70035 |
| L6-S Custom other pots listed for this model | 1981 Gibson parts list | 70029 |
| Super 400 CES other pots listed for this model | 1981 Gibson parts list | 70029 70035 |
| Super V CES other pots listed for this model | 1981 Gibson parts list | 70029 70035 |
* The 1978-80 loose leaf update sheet lists suitable replacement pots for older ones no longer available from Gibson. Many of these are of different resistance, shaft length and possibly taper.
