Gibson Pot Database: home
| Part number: | 70989 |
| Resistance: | 2.5 K |
| Taper: | - |
| Shaft length: | |
| Notes: | "BD" volume |
Models using this potentiometer
Les Paul Signature bass
pot list | instrument details
