Guild S-90

Solid body electric guitar

Guild
The Guild S-90 electric guitar
1975 Guild electric guitar catalogue

The S-90 was launched sometime around 1972, at a price of $275. It had the new SG style body shape and twin humbuckers of the S-100 yet with the simplified controls and simpler hardware of the S-50. Gibson were continually refining the SG, and the 1972 prices ran from $249 for the single pickup SG-I, to $595 for the SG custom. The Guild S-90, with its mahogany body, set mahogany neck and full body scratchplate with twin humbuckers was reminiscent of the SG special and standard of 1968-70, yet in the price range of the cheapest Gibson two pickup sg, the SG-II at $279.50

It was also available in a wider range of colours: Sunburst, Cherry, Black, Walnut, or Natural.

The description below comes from the 1975 Guild electrics catalogue

An electric that tells your friends you're moving up - because it's a Guild. The S-90 gives you the advantages of Double Humbucking Pick-Ups, besides the efficiency of high quality tuning machines, bridge, tailpiece and controls. Guild's neck and fingerboard will help you develop your style and skill.

Details: Contoured all mahogany solid body. Guild extra-fast, very thin mahogany neck with fully adjustable truss rod. Rosewood fingerboard with inlaid mother-of-pearl position dots. Natural headplate. All hardware chrome plated. Guild machines. Guild AdjustoMatic 6-way bridge. Tailpiece of solid brass. Laminated pickguard. 22 frets. Neck joins the body at 18th fret. Guild E-220 Sidebender Strings.

Electronics: 2 chrome plated Guild Humbucking Pick-Ups with individual adjustable pole pieces for each string and 3-way tilt adjustment for accurate pick-up placement. 3-position pick-up selector. Separate tone and volume controls.

Dimensions: Body 1 7/8" (32.7 cm.) wide, 16 1/2" (41.9 cm.) long, 1 5/16" (3.3 cm.) thin. Overall length 40" (101.6 cm.). Scale length 24 3/4" (62.8 cm.). Neck width at nut 5/8" (4.1 cm.).

Back to the Guild Index | comment

Guild S-90 - New Anti-Hum Pick-Ups on All Guild Guitars and BassesGuild S-90 - New Anti-Hum Pick-Ups on All Guild Guitars and Basses
This advert from December 1971 doesn't say much; letting the guitars do the talking. From Top to bottom: M75, S-50, S-90, S-100, JS bass II and JS-bass II fretless
Guild S-90 - New Solid Bodies From GuildGuild S-90 - New Solid Bodies From Guild
Early seventies Guild advert for their solid body range - featuring the new S-100, the JS basses, and the solid-body version of the BluesBird. The guitars pictured are the early versions - old styl...
Guild S-90 - Guild Electrics. Are you trying to make it without oneGuild S-90 - Guild Electrics. Are you trying to make it without one
Advert for the S-90, S-100 SF-V (starfire) and M75 Guild six strings
Guild S-90 - New Guild S-90 Solid Body! New Humbucking PickupsGuild S-90 - New Guild S-90 Solid Body! New Humbucking Pickups
Guild were very proud of their new humbucking pickups in the early 1970s; for many years they had been using pickups produced by other companies, primarily DeArmond, but also Todd electronics and S...









# # #
